Hydraulic Breaker Chisel 155mm For Excavator Jack Hammer Concrete Breaker Machine

Name: Hydraulic Breaker Chisel 155mm For Excavator Jack Hammer Concrete Breaker Machine
Brand: Yantai Dopro Industry Technology Co., Ltd.
SKU: DPBB1550
Price: 3,500.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: Dopro

Certification: ISO CE

Model Number: DPBB1550

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 1000-6000

Packaging Details: Export Wooden Cases /Pallet

Delivery Time: 5-7 Working Days

Supply Ability: 7000 Pcs Per Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Jack Hammer Concrete Breaker Machine, Hydraulic Breaker Chisel 155mm, Jack Hammer Concrete Breaker


Warranty:	12 Months	Color:	Yellow,Customer Required,White
Application:	Mining,Crawler Excavator,Construction,breaking Stone	Type:	Side Type/top Open Type /box Silenced Type,Top Type/ Side Type/ Box Type
After-sales Service Provided:	Online Support,Video Technical Support,Field Maintenance And Repair Service	Material:	42CrMo,20CrMo
Chisel Diameter:	35-195mm	Weight:	80-4000kg
Condition:	100%new	Name:	Hydraulic Hammer Rock Breaker For Excavator,Hydraulic Breaking Hammer
Part Name:	Hydraulic Hammer Rock Breaker	Product Name:	Soosan Hydraulic Breaker,Hydraulic Hammer Rock Breaker,Hammer For Excavator
Oem:	Avaliable	System:	Hydraulic-system
Oem/odm:	Acceptable

Warranty:	12 Months
Color:	Yellow,Customer Required,White
Application:	Mining,Crawler Excavator,Construction,breaking Stone
Type:	Side Type/top Open Type /box Silenced Type,Top Type/ Side Type/ Box Type
After-sales Service Provided:	Online Support,Video Technical Support,Field Maintenance And Repair Service
Material:	42CrMo,20CrMo
Chisel Diameter:	35-195mm
Weight:	80-4000kg
Condition:	100%new
Name:	Hydraulic Hammer Rock Breaker For Excavator,Hydraulic Breaking Hammer
Part Name:	Hydraulic Hammer Rock Breaker
Product Name:	Soosan Hydraulic Breaker,Hydraulic Hammer Rock Breaker,Hammer For Excavator
Oem:	Avaliable
System:	Hydraulic-system
Oem/odm:	Acceptable

Hydraulic Breaker Chisel 155mm For Excavator Jack Hammer Concrete Breaker Machine

Chisel 155mm For Excavator Jack Hammer Concrete Breaker Machine

Rock Breaker Hammer

Rock breaker is powered by an excavator or loader pump provides pressure oil, it can dig a fundamental role in building a more efficient clean up floating rock crevice in the rocks and soil. Optional hydraulic hammer excavator model is based on the principle of the operating environment to choose the most suitable hydraulic rock breaker

Hydraulic breaker has become an important tool for the job, it was installed in the hydraulic breaker backhoe loaders (also known as two busy) or wheel loader for crushing operations.

FEATURE & BENEFITS

Fuly closed housing with nose yibraion dampening system

·High-efficiercy percussion system

·Auto greasing connection

·Fuly enclosed housing wth robust structure

SPECIFICATION
Model			DPBB400	DPBB450	DPBB530	DPBB680	DPBB750	DPBB1000
Suitable Excavator	Min	ton	0.8	1.2	2.5	4	6	11
	Max	ton	2.5	3	4.5	7	9	16
	Suitable	ton	1	2	3	6	7	14
Tool (MoilType)	Weight	Kg	4	6	9	20	25	59
Tool (MoilType)	Diameter	mm	40	45	53	68	75	100
Operating Weight (Tool+MC)		Kg	102	126	152	295	375	861
Operating Weight (Tool+MC)		lb	298	320	397	683	838	1962
Height		mm	1135	1213	1317	1620	1899	2316
Operating Pressure (Breaker)		bar	80～100	80～100	90～120	95～130	100～140	150～170
Operating Pressure (Breaker)		psi	1,160～1,450	1,160~1,450	1,305~1,740	1,377～1,885	1,450~2,030	2,175～2,465
Setting Pressure (Machine)		bar	150	150	150	170	180	200
Setting Pressure (Machine)		psi	2175	2175	2175	2465	2610	2900
Impact Rate		bpm	800～1,400	700～1,200	600～1,100	500～900	400～800	350～700
BackHead Pressure (N2-Gas)		bar/psi	14/203	14/203	16/232	16/232	16/232	16/232
Required Oil Flow		l/min	15～30	20～40	25～50	40~70	50～90	80～110
Required Oil Flow

SPECIFICATION
Model			DPBB1350	DPBB1400	DPBB1500	DPBB1550	DPBB1650	DPBB1750
Suitable Excavator	Min	ton	16	18	25	28	30	40
	Max	ton	21	26	30	35	40	55
	Suitable	ton	20	24	24	34	40	50
Tool (Moil Type)	Weight	Kg	125	129	129	193	233	311
Tool (Moil Type)	Diameter	mm	135	140	150	155	165	175
Operating Weight (Tool+M/C)		Kg	1500	1766	2071	2632	3400	3991
Operating Weight (Tool+M/C)		lb	3968	4453	4453	5820	7055	11089
Height		mm	2682	2813	3063	3215	3395	3736
Operating Pressure (Breaker)		bar	160～180	160～180	160～180	160～180	160～190	160～200
Operating Pressure (Breaker)		psi	2,320～2,610	2,320～2,610	2,320～2,610	2,320～2,610	2,276~2,702	2,276～2,845
Setting Pressure (Machine)		bar	210	210	210	220	240	240
Setting Pressure (Machine)		psi	3045	3045	3045	3190	3480	3480
Impact Rate		bpm	350～600	350～500	300～450	300～450	250～400	200～350
Back Head Pressure (N2-Gas)		bar/psi	16/232	16/232	16/232	16/232	17/246	18/261
Required Oil Fow		l/min	100～150	120～180	150～210	180～240	200～260	210～290
Required Oil Fow
